- Operating voltage 12~24Vdc
- Stainless Steel housing
- Holding force up to 800lbs (363kg)
- Weather resistant: IP67
- Sealed electronics
- Voltage tolerance: ±10%.
- Current draw: 460mA at 12Vdc 230mA at 24Vdc (at temperature 20°C).
- Operating temperature: -10~55°C (14 to 131°F).
- Lock’s surface temperature: Current temperature ±20% (when power is on).
- Humidity: 0~95% non-condensing.
- Weight: 2.9kg (approx).
- Dimensions 220 × 46 × 30 mm
