- Operating voltage 12~24Vdc
- Aluminium
- Holding force up to 300lbs (136kg)
- Fail-Safe (Power to Lock)
- Status LED: RED and GREEN
- Voltage tolerance: ±15%.
- Current draw: 300mA at 12Vdc 150mA at 24Vdc(at temperature 20°C).
- Operating temperature: -10~55°C (14 to 131°F).
- Lock’s surface temperature: Current temperature ±20% (when power is on).
- Magnetic bond sensor monitor output remotely monitors the door lock or unlock status. (N.C. Output-Door opened; N.O. Output-door closed) (SPDT rated 0.25A at 12Vdc).
- Special Zinc finishes for magnet and armature plate.
- Weight: 1.2.0kg (approx).
- Dimensions 210 × 35 × 23 mm
