- Operating voltage 12~24Vac/Vdc
- Monitored
- Material: Zinc alloy main stand, Stainless Steel faceplate.
- Fail-Safe/Fail-Secure (Selectable)
- Max latch throw 18mm
- Door status output
- For wood or metal frame doors
- Long life solenoid
- Suitable for DIN standard lock-cases
- Voltage tolerance: ±15%.
- Current draw: 210mA at 12Vdc, 140mA at 24Vdc (at temperature 20°C).
- Operating temperature: -10~45°C (14 to 131°F).
- Lock’s surface temperature: Current temperature ±20% (when power is on).
- Reed switch rating: 1A/125Vac.
- Humidity: 0~95% non-condensing.
- Tested to 1,000,000 cycles (solenoid).
- 1000lbs jaw strength pull testing.
- Dimensions 202 × 36.5 × 17 mm
