- FD30 + FD60 Rating
- Operating voltage 12 or 24Vdc
- Stainless Steel
- Fail-Safe
- 1500lbs holding force
- 500lbs side-load
- Fire tested: BS EN1634:1
- 1 Hour UK fire certificate
- Voltage tolerance: ±20%.
- Current draw: 280mA at 12Vdc, 140mA at 24Vdc (at temperature 20°C).
- Operating temperature: -10~45°C (14 to 131°F).
- Lock’s surface temperature: Current temperature ±20% (when power is on).
- Humidity: 0~95% non-condensing.
- Life rating of solenoid valve: 250,000 cycles,
- Keeper width: 48mm.
- Latch throw: 15mm.
- Material: Stainless Steel.
- 1500lbs jaw strength pulls testing.
- Weight: 673g.
- Dimensions 141 × 40 × 23 mm
