- FD30 + FD60 Rating
- Operating voltage 12Vdc (24Vdc available to order)
- Stainless Steel
- Fail-safe
- Fire tested: BS EN1634:1
- 1500lb holding force
- 500lb side-load
- 1 Hour UK fire certificate
- Voltage tolerance: ±10%.
- Current draw: 280mA at 12Vdc, 140mA at 24Vdc (at temperature 20°C).
- Operating temperature: -10~45°C (14 to 131°F).
- Lock’s surface temperature: Current temperature ±20% (when power is on).
- Humidity: 0~95% non-condensing.
- Solenoids tested to 250,000 cycles.
- Weight: 673g (approx).
- Dimensions 210 × 46 × 25 mm
