- FD30 + FD60 Rated
- Operating voltage 12~24Vdc (Selectable)
- Unmonitored
- Aluminium housing
- Fire tested: BS EN1634:1
- Safety bolts fitted
- Holding force up to 600lbs (272Kg)
- Electro-less nickel plated armature
- Fail-Safe
- 1 Hour UK fire certificate
- Door status: An independent contact that works separately from the magnet to show door status not lock status
- Voltage tolerance: ±10%.
- Current draw: 480mA at 12Vdc, 240mA at 24Vdc (at temperature 20°C).
- Operating temperature: -10~55°C (14 to 131°F).
- Lock’s surface temperature: Current temperature ±20% (when power is on).
- Humidity: 0~95% non-condensing.
- Aluminum housing, nickel plated armature.
- Weight: 2.0kg (approx).
- Dimensions 228 × 38 × 27 mm
