- Operating voltage 12~24Vdc
- Aluminium
- Fail-Safe (Power to Lock)
- Holding force up to 600lbs x 2 (272Kg x 2)
- Surface mount
- Status LED: RED and GREEN
- Voltage tolerance: ±15%.
- Current draw: 500mA at 12Vdc, 250mA at 24Vdc (at temperature 20°C) for each magnet.
- Operating temperature: -10~55°C (14 to 131°F)
- Lock’s surface temperature: Current temperature ± 20% (when power is on).
- Magnetic bond sensor monitor output remotely monitors the door lock or unlock status. (N.C. Output-Door opened; N.O. Output door closed) (SPDT rated 0.25A at 12Vdc).
- Humidity: 0~95% non-condensing.
- Special Zinc finishes for magnet and armature plate.
- Weight: 4.0kg (approx).
- Dimensions 500 × 43 × 25 mm
