- Operating voltage 12Vdc
- Stainless Steel
- Allows up to 2000 IC card capacity
- Backlit keypad
- Read and register card continuously, submit card number and card code automatically
- Read card to open and close
- Operation mode: Card, code, card or code, card + code
- Door opening signal output by relay directly (NO/NC optional)
- Weather resistant: IP65
- Vandal resistant
- 2 LED displays
- With audible indication
- Operating voltage: ±10%.
- Operating temperature: -10~50°C (14 to 131°F).
- Operating current: < 0.1A
- Capacity of recording: 2000 ID Cards and 1 Group Code
- Card reading distance: 5-15cm.
- Humidity: 20~80% non-condensing.
- Weight: 0.15kg (approx).
- Dimensions 86 × 86 × 20 mm
