- Operating voltage 12~24Vdc
- ABS black plastic
- Allows up to 49+50 PIN codes
- Dual relays output for multi control
- Fully programmable via keypad and master code
- 5 digit codes only
- 3 LED displays: Red, Yellow and Green
- With audible indication
- Current draw: Pull in: 60mA/12Vdc; Holding: 15mA/12Vdc.
- Output: Dual relays, N.O./N.C/Com.
- Relays rating: 2A@30Vdc., 0.4A@120Vac.
- Memory volume: 49+50 PIN codes.
Relay 1 is controlled by 001~049 user slots.
Relay 2 is controlled by 050~099 user slots. - Dimensions 114 × 70 × 40 mm
