Press to Exit IP66 High Impact Push Button – Single Pole

From : Insight Automation

£73.08 ex vat

IP66 Ingress protection
Momentary contact
1 x Normally Open & 1 x Normally Closed Circuit
High impact
RoHS compliant
M16/20 Pre-moulded conduit knockouts

Trade Customer?

Looking to order in BULK?

Give us a call today on 01767 315 402 where we can quote you directly.

Part code: 0650-GB-PTE Categories: Illuminated, IP65/66

0650-GB-PTE is a high impact externally rated 12Vdc
Illuminated Exit Button. Equipped with a robust two part cross
polymer housing incorporating an integral gasket which seals
the product to IP66.

The switch is supplied with an externally rated bi-colour
engraved legend disc and are gasketed using an open cellular
foam which once tightened maintains the IP rating.

A highly reliable and effective solution for external egress
control requiring illumination.

Contact	Momentary
Motif	Press to Exit
Poles	Single Pole
Size	Single Gang
Illuminated	Yes

Technical

Specification

Electrical

Contact Resistance (initial)	New state ≤ 50mΩ as per DIN IEC 60512-2-4
Life	2 million Cycles of operation
Electrical strength	3000VAC, 50Hz, 1min. between all terminals and earth, as per EN IEC 61058-1-15
Insulation Resistance	> 7MΩ between the open contacts at 500 VDC, as per EN IEC 61058-1-15

Mechanical

Operating Force	6N
Contact Bounce	≤ 5ms
Travel	3mm

Environmental

Ingress Protection	IP 67
Contact Material	Gold plated silver
Actuator Material	Polyamide
Operating Temperature Range	-25° to +55°C
Shock	max. 150m/s², pulse width 11ms, 3-axis, as per EN IEC 60068-2-27
Housing	Diallylphthalate DAP, Polyamide 66, Polysulfone, heat-resistant and self-extinguishing

Material

Plate material

Robust cross polymer enclosure
