The 0659N-GB-GR is just one of the variants in the range of externally rated surface mount buttons. The robust two part cross polymer housing incorporates an integral gasket that seals the unit to IP66. The large stainless steel button has a momentary contact. The actuator is knurled which provides an excellent tactile feedback to the user.
The housings are available in two colour combinations – grey lid with a black base and black base with a highly contrasting yellow lid. Both models are easily
identifiable to the user. The base incorporates pre-moulded conduit knockouts (both M16 and M20), these aid installation by ensuring effective cable management.
Legend discs are manufactured from an externally rated bi-colour engraving
laminate which is available in a variety of colour combinations. The discs are gasketed using an open cellular foam, when the switch is tightened to the unit, the cells close to maintain the IP rating. Custom legend discs are available to special order to suit particular applications – please call to discuss your requirements.
