£951.60 ex vat
Set for 2 wing swing gates up to 7 m (3.5 + 3.5 m) complete with a 433 MHz radio receiver.
Kit for 2 wing swing gates up to 7 m (3.5 + 3.5 m)
Kit Contents:
| Description | PWR35H |
| Electromechanical actuator: | Irreversible for up to 3.5 m wide wing |
| Stroke Control: | Limit switch, magnetic limit switch (optional) |
| Maximum Capacity: | 600 kg x 1.75 m 250 kg x 3.5 m |
| Power Absorption: | 24 V DC; |
| Maximum Power: | 5.5 A |
| Power Input: | 65 W nom. / 132 W max |
| Thrust: | 3000 N |
| Opening Time: | 14÷80 s / 90° |
| Max Travel: | 450 mm |
| Actuator Maximum Opening: | 110° |
| Intermittent Operation: | 50 consecutive cycles at 20°C |
| Service Index: | Intensive: tested up to 300,000 cycles |
| Release System for manual opening: | key-operated |
| Operating Temperature: | -20°C / +55°C (-35°C / +55°C with NIO enabled) |
| Protection Level: | IP44 |
| Weight (kg): | 9 |
| Control panel: | LCU30H or LCU40H |
PWR35 – Double Swing Gate Automation Kit, 2 x 3.5m
Part Code: DITPWR35HLS PWR25 – Double Swing Gate Automation Kit, 2 x 2.5m
Part Code: DITPWR25HLS PWR25 – Complete Double Swing Gate Automation Kit, 2 x 2.5m
Part Code: DITPWR25HL
PWR35 Simplified Kit – Complete Double Swing Gate Automation Kit, 2 x 3.5m
Part Code: DITPWR35HLE
