The Ditec Cubic Kit is the ideal automation system where any interference with style, aesthetics, and elegance must be avoided.
The gear motor and the lever systems can handle gate wing of various sizes and opening angle up to 110°.
230 V AC set, with 433 MHz radio.
Kit Includes:
| Description | Cubic 6 |
| Electromechanical actuator | Irreversible for up to 4 m wide wing |
| Stroke control | Magnetic limit switch (optional) |
| Maximum capacity | 800 kg x 2 m 350 kg x 4 m |
| Service index | 3 – frequent |
| Intermittent operation | S2 = 15 min S3 = 25% |
| Power supply | 230 V AC / 50 Hz |
| Power input | 1.5 A |
| Torque | 340 Nm |
| Opening time | 18 s/90° |
| Actuator maximum opening | 110° or 180° |
| Release system for manual opening | key-operated |
| Operating temperature | -20°C / +55°C (-35°C / +55°C with NIO enabled) |
| Protection degree | IP 67 |
| Control panel | E2 LOGIC M |
Cubic – Underground Automatic Double Gate Kit, 2 x 3.5m
Part Code: DITCBHL
